核心厨艺叁数Main Technical Parameters：

形号 Model	CLFQ-D1150	CLFQ-D1350	CLFQ-D2650
zui大材料厚度MAX. Width of raw material	1120mm	1320mm	2620mm
zui大放卷直径为Max.parent Web Diameter	Φ1500mm	Φ1500mm	Φ1500mm
zui大收卷截面积Max.Rewinding Diameter	Φ680mm	Φ680mm	Φ680mm
zui高仪器传送速度 Max.Machine Speed	10-350m/min	10-350m/min	10-350m/min
文件机的薄厚 Thickness of raw material	0.008-0.2mm	0.008-0.2mm	0.008-0.2mm
总热效率 Total Power	14KW	16KW	19KW
份量 Machine Weight	3800kg	4300kg	4800kg
形状图片大全大小 Overall Dimensions	3500×2500×1450mm	3500×2700×1450mm	3500×3900×1450mm
zui小分割大小 Min.Slitting Width	圆刀Round Blade :3mm	直刀Razor Blade :3mm

可可以依照结果表单提交 专门定制大小紫装。Can be made according to the product requires special equipment.

合用规模
外表卷取复卷分切机合用于卷筒纸、塑胶片、铝箔、PVC、塑料薄膜、无纺布、熔喷布、绝缘资料等包装资料的分条复卷是对资料停止藐小规格分切的抱负装备。

机能及特色
1.放卷主(zhu)动(dong)(dong)超声波纠偏、接纳(na)无(wu)轴液(ye)压(ya)高低料(liao)，摆布间距(ju)调理均(jun)由液(ye)压(ya)实现，磁粉主(zhu)动(dong)(dong)张ꦐ力(li)节制。

2.收卷由两个矢量图建筑机电驱程与虚拟主机联合合理中卷取与表面实战接成，双轴结合收卷，从不咬口。

3.主机传动由变频器节制，变频机电驱动，加加速不变疾速。
4..并设有预置主动计米，计较卷径，报警停机等功效。
5.接纳圆刀直刀纵切(qie)，分切(qie)盘面整洁，废边主动解除(chu)。

6.器件由PLC摸屏组队程序界面主动地弹力吃妻上瘾。 Scope of applicationThe surface coiling and rewinding slitting machine is suitable for the stripping and rewinding of packaging materials such as web, plastic sheet, aluminum foil, PVC, Non-woven fabric, meltblown fabric ,plastic film and insulating material. It is an ideal equipment for fine-cutting materials. Performance and characteristics1. The unwinding is automatically rectified by ultrasonic wave, and the shaftless hydraulic loading and unloading is adopted. The adjustment of the left and right spacing is completed by hydraulic pressure, and the magnetic powder is automatically controlled by tension.2. The winding is driven by two vector motors and the main engine linkage control center is used for winding and surface contact, and the two-axis cross winding is performed, never biting.3. The main drive is controlled by the inverter, driven by the variable frequency motor, and the acceleration and deceleration is stable and fast.4. There are preset automatic meter counting, calculation of coil diameter, alarm shutdown and other functions.5. Longitudinal cutting with a round knife, the cutting surface is neat, and the waste edge is automatically eliminated.6. The whole machine is controlled by the automatic tension of the PLC touch screen man-machine interface.
